Traffic Signal Hardware

TS&L introduces a new line of DOT-approved traffic signal hardware, designed to enhance roadway efficiency, safety, and support smart city initiatives. Engineered for durability and reliability, the hardware includes advanced controllers, modular signal heads, and adaptive traffic control features. Fully compliant with DOT standards, it integrates seamlessly with existing systems and features energy-efficient LEDs and real-time monitoring. Available now for immediate shipment, this innovative solution meets the growing demand for intelligent transportation systems (ITS) to reduce congestion and improve traffic flow.

Mast Arm Clamp
Mast Arm Codes Defined
1#16 - + - *XX -YY%
# = Saddle Swivel Combination,
4,6,7,8,9
+ = Functional Use, A= Saddle Swivel Only, G=Signal Use, L=Illuminuted Sign, M=Sign Mount
* = Securement Method, B=Stainless Steel Banding, C=Stainless Steel Aircraft Cable, Z=Galv Aircraft Cable
XX = Cable Length, 48"-196" in Whole Foot Lengths, Custom Lengths Available
YY = Tube Length, 12" - 96" in Whole Foot Lengths, Refer to Signal Section Chart for Tube Length
% = Tube Style, _(blank)= Straight Tube, G=Gussetted Tube, F=Gussetted Fully Slotted
Mast Arm Signal Systems
Disconnect
Disconnet Codes Defined
190 x - c y z - a b d
x
= Size of Box, 0 is small, 1 is large
c = Color of Disconnect, Typical B for black, Y for Yellow, U for unpainted
y = Top Attachement, Typical: 3 for Tri-Stud, C for Coupling
z =Bottom Attachment, Typical: 3 for Tri-stud, C for Coupling, F for Flat (No Opening)
ab = Circuit Block Install, Typical: 00 for no Block, 12 for 12 Circuit, 18 for 18 Circuit block
d= Circuit Block Style, Typical: B for Block Only, J for Jones Plug Attachment
Ex: 1901-YC3-12J: Large Disconnect, Powder Coat Yellow, 1-1/2" NPS Coupling Top, Tri-stud Bottom, 12 circuit Jones Plug
Mast Arm Sign Mounting System
